| Specificații hardware |
| Conector de rețea |
8-Port RJ-45 for 10/100Base-TX (Port 1 to Port 8)
1-Port RJ-45 for 10/100/1000Base-T (Port 9)
|
| PoE Inject Port |
8-Port with 802.3af / 802.3at PoE injector function |
| Afișaj LED |
System: Power (Green)
Per PoE port: PoE (Orange)
LNK/ACT (Green)
Gigabit port: Speed (Green)
LNK/ACT (Green)
|
| Schimbarea arhitecturii |
Store and Forward switch architecture |
| MAC Address Table |
4K MAC address table with Auto learning function |
| Comutatorul Fabric |
3.6Gbps |
| Capacitatea de comutare |
2.67Mpps@64Bytes |
| Controlul debitului |
Back pressure for Half-Duplex
IEEE 802.3x Pause Frame for Full-Duplex
|
| Cerinte de putere |
AC 100~240V, 50/60Hz, 2.5A max. |
| Consumul de energie |
130 watts / 443BTU |
| Dimensiuni (L x Î x H) |
280 x 180 x 43 mm, 1U height |
| Greutate |
1.7kg |
| Putere peste Ethernet |
| PoE Standard |
IEEE 802.3af / 802.3at Power over Ethernet / PSE |
| Tip de alimentare PoE |
End-Span |
| Putere de ieșire PoE |
Per Port 56V DC, 350mA. Max. 15.4 watts
Per Port 56V DC, 600mA. Max. 30 watts
|
| Alocarea pinilor de putere |
1/2(+), 3/6(-) |
| PoE Power Buget |
120 watts (at room temperature) |
| Max. numărul PD de clasa 1 |
8 |
| Max. numărul PD de clasa 2 |
8 |
| Max. numărul PD de clasa 3 |
8 |
| Max. numărul PD de clasa 4 |
3 |
| Conformitate standard |
| EMI Safety |
FCC Class A, CE |
| Mediu de lucru |
0 ~ 50 degrees C |
| Mediu de stocare |
-10 ~ 70 degrees C |
| Umiditatea de funcționare |
5 ~ 95%, relative humidity, non-condensing |
| Depozitare Umiditate |
5 ~ 95%, relative humidity, non-condensing |
| Standard de conformitate |
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet
IEEE 802.3at High Power over Ethernet
|
